NST provide an easy and convenient means to setup a MySQL database engine. Once that an initial instance of a MySQL database is configured and running, one can then manage the database engine with tools found in the web interface.
The setup_mysql script is shown below. It allows for the runtime database engine to be created and run from a RAM disk or a pre-existing directory. The directory (i.e. runtime directory) can be a mount point on a locally attached disk drive or a networked file system. This allows for permanent database storage when using NST.
[root@probe root]# /usr/local/bin/setup_mysql -h
Usage: setup_mysql [-s] [-d] [-rd <RAM device>] [-rds <RAM disk size (MB)>]
[-rmp <RAM mount point>] [-rdir <runtime directory>] [-v] [-h]
This script is used to create an initial MySQL multi-user, multi-threaded SQL database
server configuration for a NST system. The default configuration will create a 64MB RAM
disk for the MySQL's database files at directory location: /mnt/ram4/var/lib/mysql.
The MySQL database server engine will be started by this script.
A "root" password will be assigned to the database. Any additional configuration to
the database will be the responsibility of the database administrator.
-s | --stop
Use this optional parameter to stop an already running MySQL database server. If this
option is not used and a MySQL database server is already running, this script will
terminate leaving the existing database server running.
-d | --delete
Use this optional parameter to delete an existing MySQL database directory
structure. This will allow one to startup a new fresh MySQL database.
** Note: This option will destroy any previous database data that may exist. Make any
necessary backups prior to using this option.
-rd <RAM device> | --ram-device <RAM device>
Use this optional parameter to change the default RAM device that will be used for this
instance of the MySQL database data files. Available RAM device names on NST:
"/dev/ram0 - /dev/ram9". A cooresponding mount point: "/mnt/ram0 - /mnt/ram9"
will be automatically selected for the RAM device. One can use the following optional
parameter: "-rmp <mount point>" to change mount point location for the selected RAM
device.
Default: "/dev/ram4"
-rds <RAM dsk size (MB)> | --ram-disk-size <RAM disk size (MB)>
Use this optional parameter to change the default RAM disk size in MegaBytes (MB) that
will be used for MySQL database data files.
Default: "64"
** Note: Use a reasonable value and make sure you to not exceed your available system RAM.
The system memory utility: "free" can be used to help make your determination.
-rmp <mount point> | --ram-mount-point <mount point>
Use this optional parameter to change the selected RAM device's: "-rd <RAM device>"
mount point for the MySQL database data files.
Default: "/mnt/ram4"
-rdir <runtime directory> | --runtime-directory <runtime directory>
One can use this optional parameter to force the setup script to use an existing
directory on a locally attached disk drive or a mounted network file system and
bypass the creation of a RAM disk. To do this, make sure the directory initially
exists prior to running this script.
Example: Mount Point: "/dev/hda1" mount at: "/probe1" type ext3 (rw)
Directory: "/probe1/mysql"
Use: "-rdir /probe1/mysql" to create the top level runtime
directory structure the MySQL database data files.
Directory Structure: mysql => /probe1/mysql/var/lib/mysql
-v | --verbose
This optional switch will enable verbose output. Without this switch set, minimal
output from the execution of this script will be displayed.
-h | --help
Displays this help information.
This script only configures and starts an initial instance of the MySQL database. It also creates a database administration user: "root" with an assigned password set to the NST clear text password. The clear text password for user: "root" can be found from the environment variable: "NSTCTPASSWD" which is generated by sourcing the NST configuration file: "/etc/nst.conf". No additional user tables or databases are created. Any configuration beyond this point will be the responsibility of the database administrator.
The following example creates a MySQL database at the runtime directory location: "/mnt/ext3/mysql". In this example, the NST probe system has a locally attached disk drive which was formatted using an Linux Ext3 file system.
[root@probe root]# setup_mysql -rdir /mnt/ext3/mysql -v
*** Creating a new MySQL database file structure at: "/mnt/ext3/mysql/var/lib/mysql"...
*** Starting up the MySQL database server...
Initializing MySQL database: [ OK ]
Starting MySQL: [ OK ]
*** Assigning a password for database user: "root"...
*** Successfully started up a MySQL database server...
*** List MySQL Database Directory...
/mnt/ext3/mysql/var/lib:
total 12
drwxr-xr-x 3 root root 4096 Jun 21 13:01 .
drwxr-xr-x 3 root root 4096 Jun 21 13:01 ..
drwxr-xr-x 4 mysql mysql 4096 Jun 21 13:01 mysql
/mnt/ext3/mysql/var/lib/mysql:
total 16
drwxr-xr-x 4 mysql mysql 4096 Jun 21 13:01 .
drwxr-xr-x 3 root root 4096 Jun 21 13:01 ..
drwx------ 2 mysql mysql 4096 Jun 21 13:01 mysql
srwxrwxrwx 1 mysql mysql 0 Jun 21 13:01 mysql.sock
drwx------ 2 mysql mysql 4096 Jun 21 13:01 test
/mnt/ext3/mysql/var/lib/mysql/mysql:
total 112
drwx------ 2 mysql mysql 4096 Jun 21 13:01 .
drwxr-xr-x 4 mysql mysql 4096 Jun 21 13:01 ..
-rw-rw---- 1 mysql mysql 8778 Jun 21 13:01 columns_priv.frm
-rw-rw---- 1 mysql mysql 0 Jun 21 13:01 columns_priv.MYD
-rw-rw---- 1 mysql mysql 1024 Jun 21 13:01 columns_priv.MYI
-rw-rw---- 1 mysql mysql 8982 Jun 21 13:01 db.frm
-rw-rw---- 1 mysql mysql 302 Jun 21 13:01 db.MYD
-rw-rw---- 1 mysql mysql 3072 Jun 21 13:01 db.MYI
-rw-rw---- 1 mysql mysql 8641 Jun 21 13:01 func.frm
-rw-rw---- 1 mysql mysql 0 Jun 21 13:01 func.MYD
-rw-rw---- 1 mysql mysql 1024 Jun 21 13:01 func.MYI
-rw-rw---- 1 mysql mysql 8958 Jun 21 13:01 host.frm
-rw-rw---- 1 mysql mysql 0 Jun 21 13:01 host.MYD
-rw-rw---- 1 mysql mysql 1024 Jun 21 13:01 host.MYI
-rw-rw---- 1 mysql mysql 8877 Jun 21 13:01 tables_priv.frm
-rw-rw---- 1 mysql mysql 0 Jun 21 13:01 tables_priv.MYD
-rw-rw---- 1 mysql mysql 1024 Jun 21 13:01 tables_priv.MYI
-rw-rw---- 1 mysql mysql 9148 Jun 21 13:01 user.frm
-rw-rw---- 1 mysql mysql 428 Jun 21 13:01 user.MYD
-rw-rw---- 1 mysql mysql 2048 Jun 21 13:01 user.MYI
/mnt/ext3/mysql/var/lib/mysql/test:
total 8
drwx------ 2 mysql mysql 4096 Jun 21 13:01 .
drwxr-xr-x 4 mysql mysql 4096 Jun 21 13:01 ..
*** List MySQL Processes...
root 902 697 0 13:01 ttyp0 00:00:00 /bin/bash /usr/local/bin/setup_mysql -rdir /mnt/ext3/mysql -v
root 965 1 1 13:01 ttyp0 00:00:00 /bin/sh /usr/bin/safe_mysqld --defaults-file=/etc/my.cnf
mysql 991 965 1 13:01 ttyp0 00:00:00 /usr/libexec/mysqld --defaults-file=/etc/my.cnf --basedir=/usr --datadir=/mnt/ext3/mysql/var/lib/mysql --user=mysql --pid-file=/var/run/mysqld/mysqld.pid --skip-locking
At this point a MySQL database engine is up and running and ready for user database and table creation. Management of the database engine can now proceed with a web-based tool found in ???.
